Available in stock
Monsoon Connect is unique in the marketplace. Optional dual 1300-CFM PowerWave blowers and stainless steel baffle filters make for a powerful, performance-driven range hood insert that is easy to clean. With a wireless remote-control option and Zephyr Connect, our most advanced operation system makes the Monsoon Connect the most quiet and energy efficient, one-piece liner available today. Dual blowers available on the 36, 42 and 48 models.
Couldn't load pickup availability
Shipping & Returns
Shipping & Returns
Most orders ship within a few business days — you will get tracking by email as soon as it is on the way. Questions about a delivery or a return? Reach our US-based team at info@improvemintfinancial.com or (855) 447-4921.
Highlights
- Minimum Installation Height Above Cooktop : 24" , see in specifications
- Standardized Width : 48" , see in specifications
- Range Hood Type : Insert , see in specifications
- Vent Style : External , see in specifications
- Maximum Installation Height Above Cooktop : 36" , see in specifications
- Vent Type : Ducted , see in specifications
- Number of Fan Speeds : 6 , see in specifications
- Control Type : Button , see in specifications
Specifications
General
| Brand | Zephyr |
|---|---|
| Model Number | AK9446BS |
| Product Name | Monsoon Connect 48 in. 700 CFM Insert Mount Range Hood with LED Light |
| Product Width | 46 3/8 inches |
| Product Depth | 19 1/4 inches |
| Product Height | 12 inches |
| Product Weight | 57 pounds |
| Warranty - Parts | 3 years |
| Warranty - Labor | 1 year |
All specifications (42)
Key specs
| Color | Stainless Steel |
|---|---|
| Vent Type | Ducted |
| Range Hood Type | Insert |
| Color Finish | Stainless steel |
| Filter Material | Pro baffle |
| Integrated Light(s) | Yes |
| Temperature Sensor | No |
| Control Type | Button |
Other
| Minimum Installation Height Above Cooktop | 24 inches |
|---|---|
| Maximum Installation Height Above Cooktop | 36 inches |
| Standardized Width | 48 inches |
| Duct Shape | Round |
| Cut-Out Width | 46 1/2 inches |
| Cut-Out Depth | 19 5/8 inches |
| Exhaust Vent Location | Top/Rear |
| Vent Style | External |
| Number of Fan Speeds | 6 |
| Delay Shut-Off | Yes |
| Auto Fan Shut-Off | Yes |
| Remote Control | No |
| Number of Lights | 4 |
| Number of Light Levels | 3 |
| Bulb Type Required | LED |
| Bulb(s) Included | Yes |
| Maximum Bulb Wattage | 6 watts |
| Maximum Air Flow Capacity | 1300 cubic feet per minute |
| Minimum Air Flow Capacity | 200 cubic feet per minute |
| Maximum Operating Sound Level | 6 sones |
| Minimum Operating Sound Level | 0.8 sones |
| Dishwasher-Safe Filter | Yes |
| Removable Grease Filter | Yes |
| Amperage | 5 amperes |
| Voltage | 120 volts |
Features
- Compatible with Zephyr Connect App The Zephyr Connect app allows customers to remotely control their range hoods from anywhere using a mobile device.
- LumiLight LED Lighting LumiLight LED lights are eco-friendly and built to last with a lifetime of more than 25,000 hours. The tri-level dimmable LEDs require less energy than traditional halogen lights, are cool to the touch, and provide uniform light distribution.
- Airflow Control Technology (ACT) Airflow Control Technology or ACT is an exclusive technology that gives installers the ability to set the maximum CFM levels to meet local code requirements.
- CleanAir Feature The CleanAir Function powers the hood on every four hours for 10 minutes to refresh the cooking area.
- Professional Baffle Filters High-airflow baffle filters that are dishwasher safe and ensure a lifetime of exceptional performance.
- Vertical or Horizontal Ducting This hood has the ability to vent either out the top or out the back.
- Optional Wireless Remote Control Our wireless remote control places the hoods operations at your fingertips from anywhere in the kitchen.
