B550M PRO-VDH WIFI is designed to support 3rd Gen AMD Ryzen and 3rd Gen AMD Ryzen with Radeon Graphics desktop processors for Socket AM4, providing reliable performance and versatile connectivity.
Couldn't load pickup availability
Shipping & Returns
Shipping & Returns
Most orders ship within a few business days. Track your order any time in your account, and many orders also get tracking by email. Questions about a delivery or a return? Reach our US-based team at info@improvemintfinancial.com or (855) 447-4921.
Highlights
- Chipset : AMD B550 , see in specifications
- Number of M.2 Slots : 2 , see in specifications
- Processor Socket : Socket AM4 (PGA 1331) , see in specifications
- Number Of PCI-E x16 Slots : 1 , see in specifications
- Form Factor : microATX , see in specifications
- Chipset Compatibility : AMD , see in specifications
- SATA Connector : 4x SATA 6G , see in specifications
- Wireless Networking Standard : Wi-Fi 6 , see in specifications
Specifications
General
| Brand | MSI |
|---|---|
| Model Number | B550M PRO-VDH WIFI |
| Year of Release | 2025 |
| Product Width | 243.84 millimeters |
| Product Weight | 29.28 ounces |
| Warranty - Parts | 3 years |
| Warranty - Labor | 3 years |
All specifications (31)
Key specs
| Memory Type Supported | DDR4 |
|---|---|
| Color | Black |
| Processor Socket | Socket AM4 (PGA 1331) |
| Number of M.2 Slots | 2 |
| Number Of Memory Slots | 4 |
| Chipset | AMD B550 |
| Form Factor | microATX |
| Maximum Memory Supported | 128 gigabytes |
| Memory Slot Type | 288-pin DIMM |
| RAID Support | RAID 0 |
| Processor Compatibility | AMD Ryzen 9 5000 Series |
| Product Name | B550M PRO-VDH WIFI (Socket AM4) AMD B550 MATX DDR4 Wi-Fi 6 Motherboard |
| Memory Format Supported | UDIMM |
| SATA Connector | 4x SATA 6G |
| Wireless Networking Standard | Wi-Fi 6 |
| Wireless Standard | AX |
Other
| Chipset Compatibility | AMD |
|---|---|
| Number Of PCI-E x16 Slots | 1 |
| Number Of PCI-E x1 Slots | 2 |
| Wireless Connectivity | Bluetooth |
| USB Ports | 6 x USB-A 2.0 |
| Number of Audio Channels | 7.1 |
| Product Length | 243.84 millimeters |
| Memory Speeds Supported | 4x DDR4 memory slots, support up to 128GB |
Features
- Processor compatibility Supports 3rd Gen AMD Ryzen/ 3nd Gen AMD Ryzen with Radeon Graphics Desktop Processors for Socket AM4
- Speed (memory speed supported) 4x DDR4 memory slots, support up to 128GB 1. Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC. Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400+ MHz by A-XMP OC MODE
- Graphics Integrated Graphics Processor
- DDR4 memory 4 DIMMs, Dual Channel DDR4 4400+MHz (OC)
- Audio 8-Channel (7.1) HD Audio with Audio Boost
