Available in stock
The MAG series was born through rigorous quality testing and designed to be a symbol of sturdiness and durability. Focused on providing the best user experience, the MAG series has a simple installation process coupled with a friendly user interface making it the best choice for entry level gamers. MAG B550 TOMAHAWK WIFI features high-bandwidth and low-latency 2.5G plus Gigabit LAN for power users. Onboard 2.5Gbps connectivity provides incredible data transfer speed faster than ever before. MSI LAN Manager automatically classifies and prioritizes the latency-sensitive for your applications, giving you the best online experience with low latency.
Couldn't load pickup availability
Shipping & Returns
Shipping & Returns
Most orders ship within a few business days — you will get tracking by email as soon as it is on the way. Questions about a delivery or a return? Reach our US-based team at info@improvemintfinancial.com or (855) 447-4921.
Highlights
- Chipset : AMD B550 , see in specifications
- Number of M.2 Slots : 2 , see in specifications
- Processor Socket : Socket AM4 (PGA 1331) , see in specifications
- Number Of PCI-E x16 Slots : 2 , see in specifications
- Form Factor : ATX , see in specifications
- Chipset Compatibility : AMD , see in specifications
- Operating System Compatibility : Windows 10, Windows 11 Home, Windows 11 Pro , see in specifications
- Number of PCI-E Slots : 3 , see in specifications
Specifications
General
| Brand | MSI |
|---|---|
| Model Number | B550TMHWKWIFI |
| Year of Release | 2021 |
| Product Width | 50.8 millimeters |
| Product Weight | 20 ounces |
| Warranty - Parts | 3 years |
| Warranty - Labor | 3 Year |
All specifications (34)
Key specs
| Memory Type Supported | DDR4 |
|---|---|
| Color | Black |
| Processor Socket | Socket AM4 (PGA 1331) |
| Number of PCI-E Slots | 3 |
| Number Of Memory Slots | 4 |
| Chipset | AMD B550 |
| Form Factor | ATX |
| Maximum Memory Supported | 128 gigabytes |
| Memory Slot Type | 288-pin DIMM |
| RAID Support | RAID 0 |
| Processor Compatibility | AMD Ryzen 7 5000 Series |
| Product Name | B550 TOMAHAWK MAX WIFI (Socket AM4) AMD B550 ATX DDR4 Wi-Fi 6E Motherboard |
| Memory Format Supported | UDIMM |
| SATA Connector | 6x SATA 6G |
| Wireless Networking Standard | Wi-Fi 6E |
| Wireless Standard | AX |
Other
| Chipset Compatibility | AMD |
|---|---|
| Operating System Compatibility | Windows 10 |
| Number of M.2 Slots | 2 |
| Number Of PCI-E x16 Slots | 2 |
| Number Of PCI-E x1 Slots | 1 |
| Wireless Connectivity | Bluetooth |
| USB Ports | 4 x USB-A 2.0 |
| Audio Ports | 1x Front Audio (JAUD) |
| Number of Audio Channels | 7.1 |
| Product Length | 304.8 millimeters |
| Memory Speeds Supported | 4866 |
Features
- Supports AMD Ryzen 7 and Ryzen Processors In an AM4 socket.
- Up to 4866+MHz 4 x DDR4 memory slots, support up to 128GB 1; Supports DDR4 1866/2133/2400/2667/2800/2933/3000/3066/3200 MHz by JEDEC; Supports DDR4 2667/2800/2933/3000/3066/3200/3466/3600/3733/3866/4000/4133/4266/4400/4533/4600/4733/4800/4866+ MHz by A-XMP OC MODE.
- AMD CrossFireX Graphics Support 1x HDMI 2.1 port, supports a maximum resolution of 4096x2160 @60Hz 1 2; 1x DisplayPort, supports a maximum resolution of 4096x2160 @60Hz 1Maximum shared memory of 16GB.
- Four 288-Pin DDR4 SDRAM DIMM Sockets Support up to 64GB of system memory.
- Audio Realtek ALC1200 Codec; 7.1-Channel High Definition Audio; Supports S/PDIF output.
- Storage 6x SATA 6Gb/s ports; 2x M.2 slots (Key M); M2_1 slot (from AMD Processor); Supports PCIe 4.0/3.0 x4 1; Supports SATA 6Gb/s; Supports 2242/2260/2280/22110 storage devices; M2_2 slot (from AMD B550 chipset); Supports PCIe 3.0x4; Supports 2242/2260/2280 storage devices.
- Expansion Slot 1x PCIe 4.0/3.0 x16 slot (PCI_E1) 1; 1x PCIe 3.0 x16 slot (PCI_E3), supports x4 speed 2; 2x PCIe 3.0 x1 slots.
- RAID Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices; Supports RAID 0 and RAID 1 for M.2 NVMe storage devices.
- USB 3x USB 3.2 Gen 1 5Gbps ports (1 Type-C internal connector, and 2 ports are available through the internal USB 3.2 Gen 1 5Gbps connector); 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors).
- LAN 1x Realtek RTL8125B 2.5Gbps LAN controller; 1x Realtek RTL8111H 1Gbps LAN controller.
- Internal Connectors 1x 24-pin ATX main power; 1x 8-pin ATX 12V power; 6x SATA 6Gb/s; 2x M.2 slots (M-Key); 1x USB 3.2 Gen 1 5Gbps Type-C port; 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports); 2x USB 2.0 connectors; 1x 4-pin CPU fan.
- Internal Connectors 1x 4-pin water-pump fan connector; 6x 4-pin system fan connectors; 1x Front panel audio connector; 2x System panel connectors; 1x Chassis Intrusion connector; 2x 4-pin RGB LED connectors; 2x 3-pin RAINBOW LED connectors; 1x TPM module connector; 1x Clear CMOS jumper.
Customer reviews
4.7
out of 5
917 customer reviews
Most recent 10 reviews
-
Everything I needed
I just began upgrading my PC, and I knew that I needed a new motherboard. This one was recommended to me by the guys at Geek Squad, and so far, I’ve had no issues.
-
Simple and easy to use
Super clean and super easy to use runs great 0 issues
-
Perfect
Looks great in the pc, works flawless, second msi board i have used and cant complain
-
Replaced broken motherboard
The geeksquad use this to replace my sons broken motherboard. Everything works as described.
-
The ease of installation
Haven’t used it yet as I’m building my computer and it isn’t completed.
-
msi b550 tomahawk
great secure budget friendly option if you wanna get into pc gaming quick and easy. great for starter builds
-
Amazing
Product was better than expected. Used daily and still holding up. Worth the cost.
-
Great motherboard
does what it needs, has 2 m.2 slots, full size board with bluetooth and wifi. Also manufactured by MSI who makes quality products with good support.
-
It’s pretty good
I like that it can connect to blue tooth because my old motherboard was basically the same model but without wifi. it’s also good because it comes with 2 nvme slots which is so helpful for me
-
Decent motherboard
Bought it to replace my dead one. It runs a ryzen 9 just fine as long as there’s airflow over the vrms.
