Available in stock
Provide robust audio performance to your home or workplace with this MartinLogan 16-channel distribution amp. Full matrix switching allows seamless use of both analog and digital inputs, while independent room correction lets you tailor sound output to individual spaces. A simple web-based setup process lets you easily configure this MartinLogan 16-channel distribution amp on site.
Couldn't load pickup availability
Shipping & Returns
Shipping & Returns
Most orders ship within a few business days — you will get tracking by email as soon as it is on the way. Questions about a delivery or a return? Reach our US-based team at info@improvemintfinancial.com or (855) 447-4921.
Highlights
- Number of Channels : 16 , see in specifications
- Minimum Frequency Response : 10Hz , see in specifications
- Maximum Frequency Response : 20 kHz , see in specifications
- Amplifier Type : Power amplifiers , see in specifications
- Amplifier Class : D , see in specifications
- Network Connector(s) : 1 x LAN , see in specifications
- Total Harmonic Distortion : 0.4 percent , see in specifications
- Number of Audio Zones : 8 , see in specifications
Specifications
General
| Brand | MartinLogan |
|---|---|
| Model Number | MDA16D |
| Product Name | 16.0-Ch. Matrix Distribution Amplifier |
| Product Width | 17 inches |
| Product Depth | 17 inches |
| Product Height | 3.9 inches |
| Product Weight | 24 pounds |
| Warranty - Parts | 3 years |
| Warranty - Labor | 3 years |
All specifications (25)
Key specs
| Color | Black |
|---|---|
| Amplifier Type | Power amplifiers |
Other
| Continuous Watts x Channel @ Ohms | 60W x 16 x 8 ohms; 120W x 16 x 4 ohms; 200W x 8 zones x 8 ohms in bridged mode |
|---|---|
| Number of Channels | 16 |
| Number of Audio Zones | 8 |
| Minimum Frequency Response | 10 hertz |
| Total Harmonic Distortion | 0.4 percent |
| Maximum Frequency Response | 20 kilohertz |
| Amplifier Class | D |
| Video Only Inputs | No video only inputs |
| Network Connector(s) | 1 x LAN |
| Line-Level Inputs | Yes |
| Speaker Connection Type | RCA |
| Video Only Outputs | No video only outputs |
| Fan Cooled | Yes |
| Bridgeable | Yes |
Features
- Rich audio performance Powers up to eight zones with 16 full channels at 60W per channel into 8 ohms (or 120W into 4 ohms). Zones can also be bridged for high-output mode with 200W per channel into 8 ohms.
- Multizone capability Allows configuring eight stereo pairs for directing audio to multiple zones to support more creative system designs and more thrilling audio performance.
- Adaptive user web-interface design Gives a user access to all functions, from sound settings to switching sources and configuring multizones, and is easy-to-use on a phone, tablet, or computer.
- Automation compatibility Robust IP/RS-232 connection capability ensures compatibility with leading home automation systems with easily downloaded drivers.
- Anthem Room Correction Integrated sound tuning technology allows you to calibrate the sound in each zone, taking into account the characteristics of the room, including the settings of the subwoofers.
- Advanced Load Monitoring technology Helps determine the electrical characteristics of acoustics and optimize output signal for a perfect result.
- Rack-mountable design Ensures flexible placement options.
- For additional information, please see the Specifications Tab.
