Personalice y ajuste completamente su audio con este procesador de matriz DSP de 8 canales de entrada y 10 canales de salida de AudioControl. El DM-810 cuenta con entradas de nivel de altavoz, nivel de línea RCA y audio digital para una variedad de escenarios de instalación, además de una interfaz de usuario inteligente que le permite controlar funciones clave como la suma de señales, ecualización, alineación temporal, retardo de entrada, AccuBASS y más. Este procesador de señal digital de ocho por diez canales también cuenta con un puerto de opciones integrado para que pueda transmitir audio de alta resolución directamente a su DSP.
No se pudo cargar la disponibilidad de recogida
Envíos y devoluciones
Envíos y devoluciones
La mayoría de los pedidos se envían en pocos días hábiles; recibirá el número de rastreo por correo electrónico en cuanto vaya en camino. ¿Tiene preguntas sobre una entrega o una devolución? Comuníquese con nuestro equipo en EE. UU. en info@improvemintfinancial.com o al (855) 447-4921.
Aspectos destacados
- Number of Channels : 10 , see in specifications
- Audio/Video Inputs : No audio/video inputs , see in specifications
- Network Connector(s) : No network connectors , see in specifications
- Audio Only Inputs : 1 x Phono, 1 x Optical digital audio, 3 x Coaxial digital audio , see in specifications
- Video Only Inputs : No video only inputs , see in specifications
- Equalizer : Yes , see in specifications
- Number of USB Inputs : 1 , see in specifications
- High Resolution Audio : Yes , see in specifications
Especificaciones
General
| Brand | AudioControl |
|---|---|
| Model Number | DM-810 |
| Product Name | 8-Channel Input 10-Channel Output DSP Matrix Processor |
| Product Width | 10.5 inches |
| Product Depth | 5.7 inches |
| Product Height | 1.6 inches |
| Product Weight | 2.6 pounds |
| Warranty - Parts | 5 years |
| Warranty - Labor | 5 years |
All specifications (29)
Key specs
| Color | Black |
|---|---|
| App Compatible | Yes |
| Wireless Connectivity | Bluetooth |
| Effect Type(s) | Octave |
Other
| Number of Channels | 10 |
|---|---|
| High Resolution Audio | Yes |
| Surround Sound Supported | Not Applicable |
| Equalizer | Yes |
| High/Low Pass Filters | Variable high pass |
| Audio Only Inputs | 1 x Phono |
| Video Only Inputs | No video only inputs |
| Audio/Video Inputs | No audio/video inputs |
| Network Connector(s) | No network connectors |
| Number of HDMI Inputs (Total) | 0 |
| Number of USB Inputs | 1 |
| Video Only Outputs | No video only outputs |
| Audio/Video Outputs | No audio/video outputs |
| Number of HDMI Outputs (Total) | 0 |
| Remote Control Included | No |
| LED Metering | Yes |
Características
- Compatible with most vehicles’ audio systems Works with both factory and aftermarket source units.
- Selectable input modes Features four sets of speaker-level inputs, four sets of RCA line-level preamp inputs, one S/PDIF input, one TOSLINK input, and five sets of RCA line-level preamp outputs for integration with your existing audio system.
- DM Smart DSP app Gives complete control of all processor tuning features via laptop or PC.
- AccuBASS processing Recovers bass frequencies lost at higher volumes.
- 30-band equalizer with auto EQ Customize how your audio sounds to get the perfect quality for your music.
- Input and output real time analyzers (RTAs) Allow you to easily identify and sum speaker signals from your factory radio.
- Internal channel summing Provides a full-range preamp signal for factory radios with built-in crossovers.
- Signal delay mode Control acoustical alignment between left and right channels as well as front and subwoofer channels.
- Variable low-pass, bandpass, and high-pass crossovers Ensure flexible operation.
- Great Turn On (GTO) Signal Sense Automatically powers the amplifier when the radio is turned on.
- Maximum Input Level Control (MILC) with clipping indicator Prevents damaging distortions and indicates input clipping on the MILC Source Clip LED.
- Option Port Provides a Bluetooth connection to allow simultaneous high-resolution audio streaming and DSP programming (AC-BT24 sold separately).
Reseñas de clientes
5.0
out of 5
4 customer reviews
Most recent 4 reviews
-
DM-810
This dsp is awesome it has all the bells and whistles eight high and lo inputs X-overs, adjustable slope, time alignment,30 band EQ, a full ten channel independently adjustable output channels all in a compact package. The setup is easy as well as the software usability.
-
AudioControl never dissapoints!!
Mecp car audio installer and 25yr car audio enthusiast. This is a spectacular piece of machinery and software. This unit gives you complete flexability in your car audio system. BUT... If you don’t have access to the appropriate test tones, RTA, O scope, signal voltage ..... to PROPERLY SET UP THIS UNIT, you just wasted some serious money. This is not for the beginner to do on his own, HIGHLY RECCOMEND professional installation AND professional tuning. Would you buy a 30 track mixing board and think you’re suddenly an audio engineer?? Probably not, then why would you buy this and think you…
-
Perfect gift
Works great. Exactly what my husband was looking for.
-
Best product
Im doing 10 channels on my car and this is the best dsp you can buy in the market
Las calificaciones y reseñas las proporciona nuestro socio.
